Carburetor FOR KAWASAKI KLX650 1996

Chassis Electrical Equipment

220

SCREW-PAN-CROS, 4X14

220D0414

220AA0414

£1,68

Unit Price Incl. Tax

223

SCREW-PAN-WS-CROS, 4X10

223C0410

223D0410

£1,96

Unit Price Incl. Tax

225

SCREW-PAN-WSP-CROS, 4X18

225C0418

225AB0418

£1,99

Unit Price Incl. Tax

11048

BRACKET CARBURETOR

110481210

Not available

11048A

BRACKET THROTTLE CABLE

110481275

Not available

13091

HOLDER NEEDLE JET

130911425

£17,74

Unit Price Incl. Tax

14025

COVER MIXING CHAMBER

140251890

£51,97

Unit Price Incl. Tax

14025A

COVER AIR CUT VALVE

140251903

£38,06

Unit Price Incl. Tax

15001

CARBURETOR-ASSY

150011803

Not available

15001A

CARBURETOR-ASSY

150011870

Not available

15001B

CARBURETOR-ASSY

150011871

Not available

16007

SEAT-SPRING DIAPHRAGM VALVE

160071113

£12,73

Unit Price Incl. Tax

16009

NEEDLE-JET N1RD

160091791

Not available

16009A

NEEDLE-JET N23P

160091792

Not available

16012

CAP-STARTER PLUNGER

160121055

£16,84

Unit Price Incl. Tax

16014

SCREW-PILOT AIR

160141061

£16,60

Unit Price Incl. Tax

16016

PLUNGER

160161057

£38,06

Unit Price Incl. Tax

16017

JET-NEEDLE

160171367

Not available

16021

SCREW-THROTTLE STOP

160211145

Not available

16030

VALVE-FLOAT

160301057

£34,12

Unit Price Incl. Tax

16031

FLOAT

160311056

£36,37

Unit Price Incl. Tax

16044

CLAMP FLOAT VALVE

16044007

£3,36

Unit Price Incl. Tax

16126

VALVE VACUUM

161261279

Not available

35011

STAY AIR CUT VALVE

350111232

£23,59

Unit Price Incl. Tax

43028

DIAPHRAGM, 5.9MM, AIR CUT V

430281053

430280016

£59,81

Unit Price Incl. Tax

49006

BOOT STARTER PLUNGER

490061165

£5,80

Unit Price Incl. Tax

92005

FITTING FUEL T-TYPE

920051112

£9,26

Unit Price Incl. Tax

92005A

FITTING L-TYPE

920051120

£17,22

Unit Price Incl. Tax

92009

SCREW 5X10

920091365

£3,94

Unit Price Incl. Tax

92009A

SCREW DRAIN M6X0.75

920091551

£5,95

Unit Price Incl. Tax

92022

WASHER PLAIN

920221003

£2,32

Unit Price Incl. Tax

92022A

WASHER PLAIN STOP SPRING

920221480

£2,74

Unit Price Incl. Tax

92037

CLAMP TUBE

920371477

£2,32

Unit Price Incl. Tax

92037A

CLAMP 55MM

920371486

£4,91

Unit Price Incl. Tax

92037B

CLAMP TUBE

920371531

£3,01

Unit Price Incl. Tax

92043

PIN, FLOAT

920431207

920431148

£5,15

Unit Price Incl. Tax

92055

RING-O PILOT ADJUST

920551002

£2,24

Unit Price Incl. Tax

92055B

RING-O

920551245

£2,89

Unit Price Incl. Tax

92055C

RING-O

920551246

£2,38

Unit Price Incl. Tax

92055A

RING-O FLOAT CHAMBER

920551222

£11,29

Unit Price Incl. Tax

92059

TUBE, 5X9X320

920591713

920591626

£15,18

Unit Price Incl. Tax

92059A

TUBE 3.5X6.5X390

920591838

Not available

92059B

TUBE 6.5X9.5X320

920591861

£10,45

Unit Price Incl. Tax

92063

JET-MAIN #140

920631013

£8,58

Unit Price Incl. Tax

92063A

JET-MAIN #135

920631014

£8,58

Unit Price Incl. Tax

92063B

JET-MAIN #138

920631015

£8,58

Unit Price Incl. Tax

92063C

JET-MAIN #142

920631016

£8,58

Unit Price Incl. Tax

92063D

JET-MAIN #132

920631076

£8,58

Unit Price Incl. Tax

92064

JET-PILOT #40

920641108

£10,40

Unit Price Incl. Tax

92066

PLUG PILOT AIR SCREW 6.9X2

920661051

£2,71

Unit Price Incl. Tax

92068

PLUG 12X25

92068006

£2,24

Unit Price Incl. Tax

92081

SPRING PILOT ADJUST SCREW

920811002

£2,96

Unit Price Incl. Tax

92081A

SPRING THROTTLE STOP SCREW

920811617

£3,17

Unit Price Incl. Tax

92081B

SPRING DIAPHRAGM VALVE

920811718

£17,09

Unit Price Incl. Tax

92081C

SPRING AIR CUT VALVE

920811719

£7,67

Unit Price Incl. Tax

92081D

SPRING PLUNGER

920811720

£6,11

Unit Price Incl. Tax

92190

TUBE 6.5X11.5X160

921901473

£4,76

Unit Price Incl. Tax

92190A

TUBE 3.5X6.5X360

921901475

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Carburetor of your Kawasaki of 1996. Let us know if you have any questions.
